Smooth and accurate reproduction of sound
This Two-Way Speaker systems provide smooth and accurate reproduction of sound while being compact and very cost-effective. All models offer the low-distortion Speaker for clear, accurate reproduction of the mid and high frequencies.
Precision Cross Over
Crossover is designed carefully after all the woofer and tweeter acoustic parameters are best obtained so that the acoustic phase is obtained accurately so that the sound sounds coherent.
Class D Power Amplifier
Using an efficient Class-D amplifier.
Fully Protection
Various protections are overcurrent (over current), overvoltage (over voltage), overheating (over heat) keep the product durable in the long term. There is a resettable fuse to protect the tweeter from damage due to excessive sound feedback when using a mic.
3 Band Tone Control
Tone control 3 bands (Treble / Mid / Bass) that are simple and easy to set for various listening room conditions. The special design of a low noise mic pre-amplifier produces clean and clear vocal sound, ideal for singing or speech.
1200 Watt
Power Output
128 dB
Maximum SPL
Class D
Power Amplifier
Full
Protection
Control
Volume Line In/Mic/Master
Sturdy
Enclosure
Acoustical
Acoustical Tuning
Bass Reflex
System
2 Way
Normal Impedance
8 Ohm
Frequency Response (-3dB)
55 – 20 kHz
Maximum SPL
127 dB
Opening Angle
110′ x 60′
LF Transducer
2 x 12 in / 300 mm
HF Transducer
Compression 1.7 in / 43 mm
Cross Over Point
1.7 kHz
Loudspeaker Power Handling
–
Amplifier
Power Output
600 W RMS / 12000 W Peak
Protection
Over Current/Voltage/Heat/HF
Control Section
Volume Line In/Mic/Master
√
Treble
10 kHz +/- 12 dB
Middle
1 kHz +/- 12 dB
Bass
100 kHz +/- 12 dB
Remote Control
√
Input/Output
Line Input Sensitivity Un-Balanced (RCA)
-6.9 dBu / 0.35 Vrms
Line Input Sensitivity Balanced (XLR)
1.4 dBu / 1.2 Vrms
Mic Input Sensitivity Un-Balanced (TRS)
-34.2 dBu / 0.015 Vrms
Mic Input Sensitivity Balanced (XLR)
-34.2 dBu / 0.015 Vrms
SD/MMC/USB Host
WAV / MP3
Bluetooth
A2DP / L2CAP / AVRCP / BT3, Simple Pairing
Radio FM
87.5 – 108 Mhz, Auto
LED Indicator
Power / Signal
Cabinet
Material
MDF
Grill
Perforated Steel (Full Front Cover)
Finish
Texture Painted
Color
Black / White
Handle
2
Mounting
Floor Stand
Physical
Dimension (HxWxD)
732 x 480 x 400 mm
Net Weight
– Kg
