Specifications:Width (Panel)=650 mm
Height (Panel)=650 mm
Depth (Panel)=30 mm
Width (Indoor Unit)=650 mm
Height (Indoor Unit)=270 mm
Depth (Indoor Unit)=570 mm
Weight (Indoor Unit)=20 kg
Width (Outdoor Unit)=800 mm
Height (Outdoor Unit)=550 mm
Depth (Outdoor Unit)=260 mm
Weight (Outdoor Unit)=37 kg
Pipe Connection=1/4 – 1/2 inch
Power Source=180V-240V / 50 Hz
Power Consumption=1.550 Watt
Current Ampere=7.3 A
Cooling Capacity=18.000 Btu/h
Refrigerant=R410A
Air Flow Volume=800 m3/h
Noise Level In (Hi/Med/Low)=46 / 40 / 35 dB(A)
Noise Level Out=55 dB(A)
Compressor Type=Single Rotary
EER=10.50
Climate Type=T1
Capacity=2 PK
Features:Auto Self Diagnosis=Yes
Auto Compressor Protection=Yes
Auto Restart=Yes
Auto Cleaning=Yes
Auto Swing Louver=4 Way
Smart Control=Yes
Turbo Mode=Yes
Timer=24 Hours
i-Feel=Yes
Low Volt (up to 180V)=Yes
Sleep Mode=Yes
Display LED Indicator=Yes
Controller=Wireless
Standard Performance=ISO – 5151
Related products
Teknologi Stream Flow Pada AC Cassette Neuva
Dimensi sirip angin lebih besar dengan sudut gerak yang lebih lebar, mengoptimalkan pendinginan ke seluruh ruangan.
Double Fan Pada AC Cassette
Pendinginan lebih cepat hingga 15% dibandingkan dengan outdoor single fan *Khusus tipe PCT 5032
Active Cleaning Function
Fitur ini dapat mencegah dan mengurangi koloni jamur, bakteri, serta endapan debu yang menempel pada evaporator.
Easy Maintenance & Installation
Front panel mudah dilepas dan filternya mudah dicuci, serta proses instalasi dan penyambungan pipanya sangat sederhana.
Specification
Width (Panel)
950 mm
Height (Panel)
950 mm
Depth (Panel)
37 mm
Width (Indoor Unit)
840 mm
Height (Indoor Unit)
298 mm
Depth (Indoor Unit)
840 mm
Weight (Indoor Unit)
33 kg
Width (Outdoor Unit)
950 mm
Height (Outdoor Unit)
1050 mm
Depth (Outdoor Unit)
340 mm
Weight (Outdoor Unit)
93 kg
Pipe Connection
3/8 – 3/4 inch
Power Source
330V-415V/3N~/50Hz
Power Consumption
4.400 Watt
Current Ampere
8.8 A
Cooling Capacity
42.650 Btu/h
Refrigerant
R410A
Air Flow Volume
2000 m3/h
Noise Level In (Hi/Med/Low)
51 / 47 / 44 dB(A)
Noise Level Out
62 dB(A)
Compressor Type
Twin Rotary
EER
9.25
Climate Type
T1
Features
Auto Self Diagnosis
Yes
Auto Compressor Protection
Yes
Auto Restart
Yes
Auto Cleaning
Yes
Auto Swing Louver
4 Way
Smart Control
Yes
Turbo Mode
Yes
Timer
24 Hours
Front Panel Display
Yes
i-Feel
Yes
Low Volt (Up to 180V)
Yes
AC Cassette Neuva
